Gensets - 750 kVA - 1500 kVA -
Canopy :
Controller :
Engine :
Alternator :
Engine capacity does matter :
Engine capacity (cc) plays a vital role in Genset performance. Higher engine capacity leads to a robust and stable Genset performance.
Higher engine capacity also enables the Genset to respond quickly & positively to sudden load additions.
| Prime Rating at rated rpm (as per IS08528 )1 | kVA | 750 HD | 900 HD | 1010 HD | 1250 HD | 1500 HD | |
| kW | 600 |
720 | 808 | 1000 |
1200 | ||
| Genset Model | KG1-750WS | KG1-900WS |
KG1-1010WS | KG1-1250WS | KG1-1500WS |
||
| Frequency | Hz | 50 | |||||
| Power factor | lagging | 0.8 | |||||
| Voltage | V | 415 30 | |||||
| Governing class (As per ISO 8528 Part-V) | G3 | ||||||
| DG set Noise level at 1 Mtr with Genset Canopy | dBA | ≤75 | Contact Kirloskar Oil Engines Ltd. for Details | ||||
| Fuel Consumption* | At 100 % Load | Ltrs/hr | 154 | 197 | 199 | 250 | 310 |
| At 75 % Load | 126.4 | 163 | 155 | 189 | 230 | ||
| At 50 % Load | 89.7 | 120 | 112 | 134 | 157 | ||
| Fuel tank capacity | Ltrs | 990 | 990 | 990 | 880 | 880 | |
| Weight of genset with canopy (approx.) | Dry | Kg | 8300 | 13600 | 13200 | 13075+ | |
| Overall dimensions of genset A | Length | mm | 6800 | 8000 | 7800 | 5650+ | |
| Width | mm | 2300 | 2300 | 2300 | 2300+ | ||
| Height | mm | 2713 | 2713 | 2713 | 2680+ | ||
| Electrical Battery starting voltage | Volts-DC | 24 | |||||
| ENGINE | |||||||
| Engine Model (Parent Engine) | DV12ETA | DV16ETA | DV16ETA | 12K4300-E2 | 12K4300-E1 | ||
| Rated output (Prime Continuous rating as per ISO No. of cylinder | 3046) | kW | 663 | 799 | 889 | 1090 | 1294 |
| HP | 901 | 1086 | 1210 | 1482 | 1760 | ||
| Number | 12 | 16 | 12 | ||||
| Cubic capacity2 | Ltrs | 23.88 | 31.84 | 51.73 | |||
| Bore x Stroke | mm | 130 x 150 | 170 x 190 | ||||
| Rated Speed | RPM | 1500 | |||||
| Aspiration | NA/IC/TA | TA | |||||
| Lube Oil change period | hrs | 500 | |||||
| Lube Oil Sump Capacity | Ltrs | 73 | 130 | 130 | 265 | ||
| Coolant Capacity with Radiator | Ltrs | 175 | 180 | 180 | 210 | ||
| ALTERNATOR | |||||||
| Insulation Class | Class H | ||||||
| Ingression Protection | IP 23 | ||||||
| Alternator Efficiency (at 100% load) 0.8 pf* | 94.6 | 95.3 | 95.1 | 95.7 | 95.4 | ||
| Alternator Efficiency (at 75% load) 0.8 pf* | 94.9 | 95.5 | 95.4 | 95.9 | 95.8 | ||
| Permissible Voltage Dip at Full Load 0.8 pf Lag | ≤ 20 % | ||||||
| Time Permitted to build up rated voltage at rated RPM | < 1 sec, provided engine should reach rated RPM | ||||||
| Short Circuit Withstand Time | sec | 3 Times rated current for "10 sec" | |||||
| Overload Withstand Capacity | % | 10% overload for one hour once in 12 hours | |||||
